| Place of Use | Roof |
| Useful Width | 1000 mm |
| Minimum Length | 2,4 m |
| Maximum Length | Depends on transport conditions. |
| Polyurethane Density (EN 1602) | 40 (±2) kg/m³ |
| Polyurethane Thickness | 40-50-60-80-100 mm |
| Flammability Class (EN13501) | B, s2, d0 |
| Metal Type | Prepainted Galvanized Steel Sheets |
| PVC Thickness | 1,2 mm |
| Standard Bottom Sheet Thickness | 0,50 - 0,60 mm |
| Unit Weight on the PVC Area | 1,55 kg/m² ±5% |
| PVC Standard Appearance | Light gray, matt |
LOAD-CARRYING CAPACITY TABLES. (PGSS) PREPAINTED GALVANIZED STEEL SHEETS
| PVC | BGS | PURLIN DISTANCE | ||||
|
Upper Membrane (mm) |
Bottom Sheet Thickness (mm) |
150 cm | 200 cm | 250 cm | 300 cm | 325 cm |
| 1,2 | 0,50 | 232 | 126 | 80 | 56 | - |
| 1,2 | 0,60 | 272 | 158 | 100 | 63 | - |
